OTR Tire Product
R-2 Series 5
- Category
- Agricultural & Implement
- Machine Group
- Agriculture / Implement
- Size Sample
- 5.00-12, 6-14, 7-16, 8.3-20, 8.3-22, 8.3-24, 9.5-22, 11.2-24...
Agricultural, paddy field, implement, irrigation and grass machinery tire applications.
Specifications
| Pattern | Size | PR | Rim | Overall Dia. mm | Section Width mm | Pressure kPa | Max Loading kg |
|---|---|---|---|---|---|---|---|
| R-2 | 5.00-12 | 6PR | 4.00E | 590 | 145 | 200 | 280 |
| R-2 | 6-14 | 6PR | 5 | 650 | 154 | 200 | 395 |
| R-2 | 7-16 | 6PR | 6 | 750 | 183 | 200 | 405 |
| R-2 | 8.3-20 | 6PR | W7 | 895 | 210 | 240 | 695 |
| R-2 | 8.3-22 | 6PR | W7 | 945 | 210 | 270 | 970 |
| R-2 | 8.3-24 | 8PR | W7 | 995 | 210 | 240 | 810 |
| M2 | 9.5-22 | 8PR | W8 | 1000 | 240 | 270 | 1135 |
| R-2 | 11.2-24 | 10PR | W10 | 1105 | 285 | 180 | 1045 |
| R-2 | 11-32 u6c34u65f1u4e24u7528 | 8PR | W10 | 1393 | 303 | 210 | 1320 |
| M1 | 8-16 | 6PR | 6 | 790 | 211 | 195 | 617 |
| M1 | 8-18 | 6PR | 6 | 841 | 211 | 240 | 650 |
| M3 | 12.4-24 | 10PR | W11 | 1160 | 315 | 230 | 1415 |
| M2 | 13.6-26 | 12PR | W12 | 1260 | 345 | 250 | 1790 |
Product Inquiry
Ask about R-2 Series 5 tire supply.
Send the size, quantity, application and destination. We will help confirm available options and quotation details.
